A practical housing starts with the screen, internal modules and installation space that it needs to accommodate.

Hongming Sheng fabricates custom sheet metal enclosures for embedded controllers, touchscreen terminals, smart panels and sensor gateways. We work from customer drawings and equipment layouts to define the front panel, internal mounting and enclosure assembly.

Whether the unit is installed on a wall, recessed into a panel or placed on a desktop, the housing can be reviewed around the actual display module, connectors and service requirements.

Email: info@hms1688.com

Send Enclosure Drawing

Embedded Enclosure and Smart Terminal References

Examples of front-panel openings, display housings and mounting arrangements. Each project follows its own component layout and fabrication requirements.

Front-Panel Opening Wall-mount embedded control housing		Display Terminal Housing Two-tone enclosure configuration
Ventilation and Mounting Side openings and mounting flanges		Compact Touchscreen Case Housing for an interface module

Start with the Display and Internal Assembly

Display, Buttons and Indicators

Provide the display module dimensions, visible screen area, mounting method and required front-panel appearance. Button, LED and sensor openings can be arranged around the approved panel layout.

PCB, Wiring and Connector Space

Share the PCB outline, mounting points, standoff positions and wiring space. Side or rear openings for USB, Ethernet, power and other connectors should be shown together with the internal assembly layout.

Covers and Maintenance Access

Screw-fixed covers, snap-fit features or magnetic cover concepts can be reviewed according to the project. Identify the parts that require access and the retention requirements for the cover.

Choose the Installation Format

Appearance and Surface Finish

Powder coating and anodizing for suitable aluminum parts are available according to the enclosure specification. Define the color, texture, visible surfaces and any logo or panel-marking requirements before production.

Material, thickness and finish can be reviewed together with the panel structure, joining method and assembly requirements.

Use the Prototype to Check the Complete Fit

A sample enclosure gives your team an opportunity to check screen alignment, PCB installation, cable access and the selected mounting format. Record any adjustments in the drawing revision before moving to the next production stage.

For repeat supply, confirm the approved drawings, assembly scope, inspection points and packing requirements. Hongming Sheng supports prototype development and production based on the agreed enclosure specifications.

NDA support: Customer drawings, CAD files and project specifications are treated as confidential. NDA agreements are available for OEM enclosure projects.
